DIMENSIONAL METROLOGY AT FARE LABS
Dimensional metrology is the science of measuring physical characteristics such as length, width, height, and diameter with a high degree of accuracy and precision. It forms the foundation of quality, safety, and compliance across industries like manufacturing, aerospace, automotive and engineering.


Basic Dimension focuses on routine measurement tools such as rulers, tape measures, callipers, and scales. These instruments are calibrated to ensure they meet specified requirements, making them suitable for everyday inspection, quality checks, and general engineering tasks.


Precision Dimension involves highly accurate measurement equipment, including micrometers, dial indicators, optical flats, gauge blocks, and other precision devices. The Calibration of these tools guarantees reliable and traceable results for critical applications such as precision machining, research, and design.


With state-of-the-art equipment and highly trained personnel, FARE Labs provides comprehensive calibration services across both basic and precision dimensional metrology. This ensures that every instrument delivers accurate, repeatable, and trustworthy results, supporting quality, compliance, and safety across industries.

S. No.Instruments NameParameter to be calibratedRangeStandard Used
12D Linear Height Gauge Deviation in Height, Squareness0-500 mmGauge Block Set (0), Caliper Checker
2Air Gauge UnitDeviation in diameter-80 µm to +80 µmSet of Plain Ring Gauge & Plug Gauge
3Angle Gauge BlocksAngleupto 45°Gauge Block Set (0), Sine Bar and Electronic Probe
4Bench CenterCo-axiality, Parallelismup to 300 mmTest Mandrel(Taper&
Straight) & Plunger Type Dial Gauge
5Bevel ProtractorAngle90°-0-90°Angle Gauge
6Bevel Protractor LC: 1′ a)AngleAngle0 to 360 °Using Angle Gauges by Direct Method
7Bridge Cam GaugeAngle, LinearThe flatness of the baseVision Measuring Machine
8Brinell Ball IndenterAngle, Linearup to 10 mmVision Measuring Machine
9Calipers (Dial / Digital/
Vernier)
ID, OD, Depth & External/Internal Jaw Parallelism0 to 2000 mmGauge Block Set (0), Caliper Checker, Length Bar & Gauge Block Accessories
10Coating Thickness GaugeThickness10 µm to 1200 µmStd. Foil Set
11Cobb TesterDiameter11 mm to 12 mmDigital caliper
12Combination Sets Angle up to 90° Angle Gauge Set
13Comparator Stand Flatness of the baseupto 120 mmLever-type Dial Gauge
14Cone MasterAngle 15° to 90°Vision Measuring Machine
15Cross Hatch Cutterup to 3.0 mmGauge Block Set (0), Master CylinderVision Measuring Machine
16Cube MouldLength/Breadth/Height150X150X150mm 2D Height Gauge
17Cylindrical SquareSquarenessup to 500 mmGauge Block Set (0),Master Cylinder
18Degree Protractor Angleupto 90°Angle Gauge Set
19Depth Gauges Depth0 to 600 mmGauge Block Set (0), Length Bar Set
20Depth Master (Step gauge)Depth1µm to 18 µmSurface Roughness Tester
21Depth Micrometer Depth0 to 300 mmGauge Block Set (0), Length Bar Set
22Dial Bore Gauge / Bore Gauge Linear transmission upto 2.0 mm (Transmission only)Length Measuring Machine(ULM), Plunger Type Dial Gauge
23Dial Calibration TesterDeviation0 to 25.0 mmGauge Block Set, Electronic Probe
24Snap Gauge Gap Size & Parallelismup to 200 mmLength Measuring Machine(ULM), Master Setting Ring Gauge.
25Dip TapeDeviation in Length0 to 30 mMeasuring Scale & Tape Calibrator
26Electronic Level/ Digital Level Meter Error in Electronic level
reading over the entire
range
up to 2.0 mmRobost Tilting Table With Indicator
27Electronic Probe with DRO /LVDTError in Electronic Probe reading over the entire range0 to 25.0 mmGauge Block Set
28Elongation Gauge / Length GaugeLength14.7 mm to 81 mmDigital Caliper/ Video Measuring Machine
29Engineer Parallel / Parallel BlocksThickness and width
Variation in Thickness
Parallelism
Equality of pairs
up to 300 mmDial Indicator, Gauge Block Set & Surface Plate
30Engineer Square / Try Square Straightness of blade edge
&
Parallelism of blade edge &
stock/ base
Squareness of external
square
Squareness of internal
square
up to 500 mmUsing Master
cylinder, Dial/Digital
Indicator, Gauge
Blocks and surface
plate
31Extensometer L.C. 1 µmGap0 to 150 mmUsing the Gauge Block Set by the Direct Method
32External Micrometer Micrometer Screw Error
(Error of Measurement)
Flatness of anvils
Parallelism of anvils
(0-1000) mmGauge Block Set, Length Bar
33Feeler GaugeThickness0.03 mm to 1 mmUsing Length Measuring Machine by Direct Method
34Flakiness Gauge (Thickness Gauge)Thickness4.89 mm to 33.90 mmVideo Measuring Machine
35Floating Carriage Diameter Measuring Machine (FCDM)Overall Accuracy,
Micrometer Head Error,
Alignment of centers to
base,
Parallelism of micrometer
face to line of centers
up to 100 mmUsing Setting
Cylinder, Mandrel
and Gauge Block Set
36Foil /Standard FoilsThicknessup to 1 mmLength Measuring Machine (ULM)
37Gauge Block AccessoriesFlatness
Parallelism
up to 25 mmElectronic Probe & Optical Flat
38Gauge Block CalibratorDeviation up to 100 mmGauge Block Set 11 Pcs
39Gauge BlocksDeviation in Lengthup to 100 mmGauge Block Comparator
40Gear Tooth VernierLengthup to 50 mmUsing Gauge Block
41Groove Micrometer Groove Widthup to 100 mmGauge Block Set
42GSM CutterDiameterup to 113 mmVideo Measuring Machine
43Hegman GaugeThicknessup to 100 µmElectronic Probe with comparator stand
44Height Gauge Height(0-600) mmCaliper Checker/Slip Gauge/ Length Bar
45Height Micrometer / Height MasterHeightUpto 300 mmUsing Lever Dial
Gauge & Check
Master Depth/Height
Master Gauge
Blocks, Surface Plate
& Electronic Probe
46Hi-Lo GaugeError in Scale (0-32) mmVision Measuring Machine
47Inclinometer Resolution:0.01°Angle/ Inclination0 to 180 °Using Angle Gauge Set by Direct Method
48Industrial Angle Gauge
(Plate Type)
Angle1 ° to 90 °Using VMM (Vision
Measuring Machine) by
Direct Method
49Industrial Inspection
Gauge/ Inspection Jig & Fixture/ Special Gauge
Geometrical
Dimension
0 to 300 mmUsing Digital Caliper &
VMM (Vision Measuring
Machine) by Direct
Method
50Internal Micrometer (Caliper Type) Error in Length5 to 30 mmGauge Block Set & Gauge Block Accessories
51
Length Measuring Machine (ULM)
Lengthup to 600 mmGauge Block Set
52Lever Arm (Ball Diameter)Ball Diameter( up to 2 mm)Vision Measuring
Machine
53Lever Dial IndicatorDeviation in Dialup to 1 mmLength Measuring
Machine (ULM)
54Limit GaugesGap /Diameter3to 100 mmLength Measuring
Machine (ULM)
55Measuring Pins / Pin GaugeDiameterup to 20 mmLength Measuring
Machine (ULM)
56Measuring Prism/ Thread Measuring Prisma) Height b)
Parallelism
3 mm to 6 mmUsing Electronic Probe with Comparator Stand by Direct Method
57Measuring Prism/ Thread Measuring PrismAngle0 to 45 °Using VMM (Vision
Measuring Machine) by
Direct Method
58Measuring Steel Rule / Steel ScaleDeviation in Lengthup to 3000 mmMeasuring Scale & Tape Calibrator
59Measuring Tape / Pie TapeDeviation in Lengthup to 100 mMeasuring Scale & Tape Calibrator
60Micrometer HeadDeviation in Lengthup to 25 mmLength Measuring
Machine (ULM)
61Micrometer Setting RodDeviation in lengthup to 1000 mmLength Measuring
Machine (ULM) & Length Bar
62Mould
(Cylinderical/Cube/
Beam & Bar Type)
a) Length/Width/
Height/ Depth/
Thickness b) Diameter
0 mm to 300 mmUsing Digital Caliper by
Direct Method
63Needle (Vicat Apparatus/Penetrometer) Length/DiameterLength/Diameter0 to 50 mmUsing Digital Caliper by Direct Method
64Nozzle (Orifice/ Industrial
Cleaning/ Fuel Injector/
(Diameter/Length)
Diameter0.1 to 50 mmUsing VMM (Vision
Measuring Machine) by
Direct Method
65Measuring Tape / Pie Tape Deviation in Lengthup to 50 mMeasuring Scale & Tape Calibrator
66Micrometer Head Deviation in Lengthup to 25 mmLength Measuring Machine (ULM)
67Optical FlatsFlatnessup to 100 mm diameterMonochromatic Light Source with Master Optical Flat
68Optical Microscope Linear & Magnificationup to 300 mm & Magnification 10X to 1000XGlass Scale, Stage Micrometer
69PCD GaugePitch Circle Diameterup to 100 mmVision Measuring Machine
70Penetrometer Thickness(0-40) mmGauge Block Set
71Pistol Caliper Thickness(0-100) mmGauge Block Set
72Pitch MicrometerPitch(0-25) mmGauge Block Set
73Plain Gap Gauge / Hub Gauge Gapup to 200 mmLength Measuring Machine (ULM)
74Plain Plug GaugesDiameterup to 100 mmLength Measuring Machine (ULM)
75Plain Taper Plug GaugeDiameter & Half Taper Angle5 to 100 mmLength Measuring Machine (ULM)
76Plunger Dial/Digital Indicator Deviation in total length(0-25) mmLength Measuring Machine (ULM)
77Profile Gauge/ Profile of work pieceProfileup to 100 mmVision Measuring Machine
78Profile Projector / Video Measuring Machine Length, Angle & Magnificationupto 300 mm, Angle upto 90° & Magnification 10X to 100XGlass Scale, Angle Gauge, Gauge Block & Digital Caliper
79Radius GaugeRadius1 mm to 40 mmVision Measuring Machine
80Raiser Blocks (Mean height of riser blocks)Mean Height upto 150 mm2D Linear Height Gauge
81Receiver GaugeLengthup to 200 mmVision Measuring Machine
82Reference Discs (Diameter at four positions Roundness)Diameterup to 100 mmLength Measuring Machine  (ULM)
83Ring & Ball Apparatus As
per IS 1205-1985
(Diameter/Length)
Diameter6.4 mm to 20.6 mmUsing VMM (Vision
Measuring Machine) by
Direct Method
84Sine Bar/ Sine CenterAngle, Center to Center Distanceupto 300 mmAngle Gauge Set, Gauge Block Set & Electronic Probe
85Slump Conea) Top Diameter
b) Bottom Diameter c) Total Height
d) Thickness of Wall
0 to 300 mmUsing Digital Caliper by
Direct Method
85Spirit LevelBubble Accuracy
Repeatability
up to 300 mmRobust Tilting Table with Digital Indicator
86Stage MicrometerDeviation in Lengthup to 1 mmVision Measuring Machine
87Caliper CheckerPitch Block Accuracy
(Length)
up to 600 mmGauge Block Set, Length Bar & 2D Linear Height Gauge
88Straight EdgeStraightness, Flatness & Parallelismup to 1000 mmGauge Block Set, Lever Type Dial Gauge & Surface Plate
89Surface Plate (Granite/Cast Iron)Flatness & Repeatabilityup to 1600 mm x 1000 mmDigital Level Meter
90Surface Roughness SpecimensSurface Roughnessup to 12.5 µmSurface Roughness Tester
91Surface Roughness Tester Depth
Surface Roughness
Parameters, Noise
1 µm to 15 µmSurface Roughness Masters, Depth Roughness Master & Optical Straight Edge
92Tape & Scale CalibratorLength Deviationup to 1000 mmLength Bar Set & Lever Type Indicator
93Taper Ring GaugeDiameter10 mm to 100 mmLength Measuring Machine (ULM), Master Ring Gauge
and slip gauge
94Taper ScaleWidth0.1to 60 mmVision Measuring Machine
95Taper Thread Plug GaugeEffective Diameter3 mm to 100 mmLength Measuring Machine (ULM)
96TemplatesLength , Angle &  Radius/Diameterup to 100 mm (Linear) & upto 90° (Angle)Vision Measuring Machine
97Test Mandrel (Straight)Variation in diameter
Total Runout
upto 300 mmBench Center & Dial Indicator
98Test Mandrel (Taper)Variation in diameter
Total Runout
Half Taper Angle
upto 300 mmBench Center & Dial Indicator
99Test SievesAperture Size & Wire Daimeter0.032 to 100 mmVision Measuring Machine/ Digital Caliper
100Thread Measuring Wires Diameter0.17 mm to 6.350 mmLength Measuring Machine (ULM)
101Thread Pitch GaugePitch0.3 mm to 6.0 mmVision Measuring Machine
102Thread Plug Gauges Effective Diameter3 mm to 100 mmLength Measuring Machine  (ULM)
103Thread Ring Gauge/Taper Thread Ring GaugeEffective Diameter4 mm to 100 mmLength Measuring Machine & Master Ring Gauge
104Three Point Micrometer / Holetester/3 Pin Bore Gauge/Bore ComparatorDiameter8 mm to 16 mm & 50 mm to 63 mmMaster Ring Gauge Set
105Ultrasonic Thickness GaugeThicknessup to 300 mmSteel Gauge Block Set &  Steel Length Bar
106V’ BlockParallelism of axis of Vee
to base surfaces
Parallelism of axis of Vee
to side surfaces
Matching tolerance of V
Parallelism of axis of Vee
to base surfaces
Parallelism of axis of Vee
to side surfaces
Matching tolerance of V
axes above the base
up to 150 mmGauge Block Set, Lever Type Dial Gauge, Surface Plate & Straight Mandrel
107Vicat Apparatus Mould/
Penetrometer Mould
(Diameter/Depth)0 to 75 mmUsing Digital Caliper by
Direct Method
108Vickers Diamond cone IndenterAngle and Cone Heightupto 5 mm (Linear) & upto 120° (Angle) Vision Measuring Machine
109Weld Fillet GaugeFillet0to 50 mmVision Measuring Machine
110Weld GaugeAngle upto 90 °Vision Measuring Machine
111Wet Film Thickness GaugeThickness(25-3000) µmVision Measuring Machine
112Wire GaugeGap Size(0.19 to 8.23) mmVision Measuring Machine
  • Calipers up to 600 mm, Height Gauge up to 600 mm
  • Dial Guage, Digital Indicator, Lever Dial Gauge up to 25 mm
  • Test Sieve from 4 mm to 100 mm Aperture Size
  • Surface Plate
  • Pin Set, Wire set
  • Plain Plug Gauge, Thread Plug Gauge upto 100 mm
  • Vision Measuring Machine, Profile Projector, Travelling Microscope
  • Plain Plug Gauge, Plain Ring Gauge, Thread Plug Gauge, Thread Ring Gauge, Taper Plug Gauge, Taper Ring Gauge, Taper Thread Plug Gauge, Taper Thread Ring Gauge, Dial Gauge, Bore Gauge, Snap Gauge, Calipers, Length Bar
  • V Block, Riser Block, Comparator Stand
  • Length Bar, Caliper Checker, Dial Calibration Tester, Sine Bar, Riser Block, Thickness Foil Set (Shims)
  • Engineer Square / Try Square, Squareness of 2D Height Gauge
  • 3-Point Micrometer, Air Gauge Unit
  • Measuring Scale up to 3 m, Measuring Tape, Circumference Tape (Pi-Tape), Dip Tape up to 50 m
  • Optical Flat, Flatness of Anvil
  • Surface Roughness Specimen
  • Clinometer, Angle Gauge Set
  • Coating Thickness Gauge up to 1 mm
  • Bevel Protractor, Combination Set, Clinometer, Sine Bar, Profile Projector, Vision Measuring Machine
  • Surface Roughness Tester (Portable /Bench Type)
  • Electronic Level, Spirit Level, Frame Level
  • Calipers (Digital/ Dial/Vernier) up to 3 m, OD Micrometers, Measuring Scale & Tape Calibrator, Floating Carriage Diameter Measuring Machine, Length Measuring Machine, Height Gauge, Linear Height Gauge, Gauge Block Calibrator with M11 Gauge Block, Depth Gauge, Depth Micrometer, Snap Gauge, Gear Tooth Vernier, Groove Micrometer, Internal Micrometer, Penetrometer, Pitch Micrometer, Pistol Caliper, Plain Gap Gauge, Sine Bar, Ultrasonic Thickness Gauge, Riser Block
  • Test Sieve from 5 microns to 4 mm, Radius Gauge, Weld Gauge, Weld Fillet Gauge, Angle Gauge, Bridge Cam Gauge, Brinell Ball Indenter, Cone Master, Cross Hatch Cutter, Degree Protractor, Flakiness Gauge, GSM Cutter Specimen, Hi-Lo Gauge, Lever Arm Ball Diameter, Receiver Gauge, Rockwell Diamond Cone indenter, Stage Micrometer, Taper Scale, Templates, Thread Pitch Gauge, V-Notch Gauge, Wet Film Thickness Gauge
  • Gauge Block 0 Grade, K Grade, 1 Grade, and 2 Grade
  • Advanced Infrastructure: We utilize cuttingedge equipment and precision standards to ensure bestinclass measurement and calibration.
  • Expert Team: Our skilled and trained professionals understand your needs and deliver results you can trust.
  • Compliance & Traceability: All calibrations adhere to international standards and NABL traceable norms for absolute reliability.
  • Quality You Can Depend On: Minimize downtime, reduce waste, and maintain the highest quality across your products and processes.
CONTACT US FOR SERVICES
Please enable JavaScript in your browser to complete this form.

Get in Touch for Our Services

Please enable JavaScript in your browser to complete this form.
